فلومتر IFM مدل SI5010

Product characteristics
Number of inputs and outputs Number of digital outputs: 1
Process connection M18 x 1,5 internal thread
Application
Media Liquids; Gases
Medium temperature [°C] -25…80
Pressure rating [bar] 300
MAWP (for applications
according to CRN) [bar] 208
Liquids
Medium temperature [°C] -25…80
Gases
Medium temperature [°C] -25…80
Electrical data
Operating voltage [V] 18…36 DC
Current consumption [mA] < 60
Protection class III
Reverse polarity protection yes
Power-on delay time [s] 10
SI5010
Flow monitor
SID10ADBFPKG/US-100
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — SI5010-04 — 09.07.2013 —
Inputs / outputs
Number of inputs and outputs Number of digital outputs: 1
Outputs
Total number of outputs 1
Output signal switching signal; IO-Link; (configurable)
Electrical design PNP
Number of digital outputs 1
Output function normally open / normally closed; (parameterisable)
Max. voltage drop switching
output DC [V] 2.5
Permanent current rating of
switching output DC [mA] 250
Short-circuit protection yes
Type of short-circuit
protection pulsed
Overload protection yes
Measuring/setting range
Liquids
Setting range [cm/s] 3…300
Greatest sensitivity [cm/s] 3…100
Gases
Setting range [cm/s] 200…3000
Greatest sensitivity [cm/s] 200…800
Accuracy / deviations
Repeatability [cm/s] 1…5
Note on repeatability
for water 5…100 cm/s; 25 °C
Factory setting
Temperature drift [cm/s x 1/K] 0.1; (for water 5…100 cm/s; 10…70 °C)
Temperature gradient [K/min] 300
Switch point accuracy [cm/s] ± 2…± 10; (for water 5…100 cm/s; 25 °C; Factory setting)
Hysteresis [cm/s] 2…5; (for water 5…100 cm/s; 25 °C; Factory setting)
Response times
Liquids
Response time [s] 1…2; (for a temperature gradient: 1 K/min)
Gases
Response time [s] 1…10
Software / programming
Adjustment of the switch
point pushbutton
SI5010
Flow monitor
SID10ADBFPKG/US-100
ifm electronic gmbh • Friedrichstraße 1 • 45128 Essen — We reserve the right to make technical alterations without prior notice. — EN-GB — SI5010-04 — 09.07.2013 —
Interfaces
Communication interface IO-Link
Transmission type COM2 (38,4 kBaud)
IO-Link revision 1.1
SDCI standard IEC 61131-9
Profiles Smart Sensor: Process Data Variable; Device Identification
SIO mode yes
Required master port type A
Process data analogue 2
Process data binary 2
Min. process cycle time [ms] 3
Supported DeviceIDs
Type of operation DeviceID
Default 54
Operating conditions
Ambient temperature [°C] -25…80
Storage temperature [°C] -25…100
Protection IP 65; IP 67
Tests / approvals
EMC
DIN EN 61000-6-2
DIN EN 61000-6-3
Shock resistance DIN IEC 60068-2-27 50 g (11 ms)
Vibration resistance DIN EN 60068-2-6 20 g (55…2000 Hz)
MTTF [years] 298
Mechanical data
Weight [g] 248.5
Dimensions [mm] M18 x 1.5
Thread designation M18 x 1.5
Materials stainless steel (1.4404 / 316L); stainless steel (1.4301 / 304); PC; PBT-GF20; EPDM/X
Materials (wetted parts) stainless steel (1.4404 / 316L); O-ring: FKM 80 Shore A
Process connection M18 x 1,5 internal thread
Displays / operating elements
Display function 10 x LED, three-colour
Remarks
Pack quantity 1 pcs.
Electrical connection
Connector: 1 x M12
